Customise the data-quality rule pack ¶

When to use this ¶

GMNS defaults are designed for typical mid-sized urban networks. Override them when:

• Your network’s speed limits, lane counts, or geometry tolerances differ from the defaults (a 30 mph residential cap, or a CRS in degrees instead of meters).
• You want to silence a rule that’s noise on your data.
• You want to plug in a project-specific quality rule.

Quick example ¶

Tighten the residential-speed threshold from the default 35 mph down to 30 mph. RuleConfig.thresholds merges into the rule’s defaults — you only specify the keys you want to change:

from netstead import Network
from netstead.fixtures import leavenworth
from corral.quality import run_quality, RuleConfig

net = Network.from_source(leavenworth.csv_dir())
report = run_quality(
    net,
    config={"quality.high_speed_residential": RuleConfig(thresholds={"speed_limit_mph": 30.0})},
)
print(f"{len(report.issues)} issues at the lower 30 mph threshold")

Quality report card. The custom 30 mph threshold surfaces a handful of extra residential-speed warnings that the default 35 mph threshold would have hidden.

Step-by-step ¶

1. List the rules currently registered ¶

Inspect the registered rule pack to see codes, defaults, and severities. The GMNS pack ships seven rules out of the box:

from corral.quality import list_rules, get_rule
from netstead.quality import register_all

register_all()                                   # populate the registry
for code in list_rules():
    rule = get_rule(code)
    print(f"{rule.code:42} {rule.severity.value:8} {rule.description[:50]}")

2. Override a threshold ¶

RuleConfig.thresholds is merged into the rule’s defaults — you only specify the keys you want to change. Override multiple rules in one call:

report = run_quality(
    net,
    config={
        "quality.high_speed_residential": RuleConfig(thresholds={"speed_limit_mph": 25.0}),
        "quality.sharp_angle_bend": RuleConfig(thresholds={"min_angle_deg": 45.0}),
    },
)

3. Disable a rule entirely ¶

A disabled rule produces no issues and isn’t listed in the report:

report = run_quality(
    net,
    config={"quality.orphan_node": RuleConfig(enabled=False)},
)

4. Promote (or demote) severity ¶

A common case: your CI pipeline should fail on lane-count mismatches even though the rule ships as WARNING. Use severity_override to promote, then check report.issues and exit non-zero accordingly:

import netstead
from netstead.fixtures import leavenworth
from corral.quality import RuleConfig, run_quality
from corral.reports import Severity

net = netstead.read(leavenworth.csv_dir())
report = run_quality(
    net,
    config={"quality.lane_count_mismatch": RuleConfig(severity_override=Severity.ERROR)},
)
has_errors = any(i.severity is Severity.ERROR for i in report.issues)
# In a CI script: sys.exit(1 if has_errors else 0)

5. Write your own rule and register it ¶

A rule is a class with five attributes plus a run generator. Yield one Issue per finding; let config.severity_override win if it’s set so callers can promote / demote the rule:

from corral.quality import Rule, register_rule
from corral.reports import Issue, Severity, Category

class NoTollLinksRule(Rule):
    code = "quality.no_toll_links"
    description = "Project networks should not contain toll links."
    severity = Severity.WARNING
    applies_to = ("link",)  # which tables the rule needs

    def run(self, net, config):
        links = net.tables["link"].to_pandas()
        for row in links[links["toll"] > 0].itertuples():
            yield Issue(
                code=self.code,
                severity=config.severity_override or self.severity,
                category=Category.DATA_QUALITY,
                message=f"link {row.link_id} has nonzero toll",
                table="link",
                row=row.Index,
                fix_hint="set toll=0 or remove from project scope",
            )

register_rule(NoTollLinksRule())

For auto-registration on import, declare the rule via the corral.quality.rules entry point in your package’s pyproject.toml:

[project.entry-points."corral.quality.rules"]
no_toll_links = "myproject.rules:NoTollLinksRule"

Common variations ¶

report = run_quality(
    net,
    config={"quality.high_speed_residential": RuleConfig(thresholds={"speed_limit_mph": 30.0})},
)

report = run_quality(net, config={"quality.orphan_node": RuleConfig(enabled=False)})

report = run_quality(
    net,
    config={"quality.lane_count_mismatch": RuleConfig(severity_override=Severity.ERROR)},
)

[project.entry-points."corral.quality.rules"]
no_toll_links = "myproject.rules:NoTollLinksRule"

Pitfalls ¶

• epsilon_units is CRS-sensitive. The default 1e-5 is tight for WGS84 degrees (~1 metre near the equator). A network in projected meters needs something like epsilon_units=0.5 for the same intent. Always set this explicitly for non-WGS84 networks.
• severity_override doesn’t mute — it replaces. Setting severity_override=Severity.INFO on a WARNING rule still produces issues; if you want to drop them, use enabled=False.
• Custom rules need applies_to. A rule that touches the signal table without listing it in applies_to won’t be invoked on networks that lack the table — the runner skips it silently.

See also ¶

• Quickstart — the default quality flow.
• API reference — run_quality, RuleConfig, Rule, Issue.
