Wire the MCP server to Claude Code / Claude Desktop ¶

When to use this ¶

You want an AI agent (Claude Desktop, Claude Code, any MCP-aware host) to call netstead directly via tool calls — describe a package, run validation, scope a subgraph, run the quality pack — instead of you copying CLI output into the chat. The MCP server speaks the Model Context Protocol so the agent treats netstead as a first-class tool surface.

Quick example ¶

Add this entry to your MCP host config, restart the host, and ask the agent “describe the package at /tmp/leavenworth/csv”. The agent picks describe_package, calls it with {"source": "/tmp/leavenworth/csv"}, and surfaces the package name, engine, table count and each table’s row count and columns back in chat:

{
  "mcpServers": {
    "netstead": {
      "command": "netstead",
      "args": ["mcp", "serve"]
    }
  }
}

Once connected, Claude lists the seven netstead tools and calls them with the source path you name; the tool name, its arguments and the JSON reply appear inline in the chat.

Step-by-step ¶

1. Install ¶

The [mcp] extra brings in mcp (the official Python SDK, v1 API). Add [graph] too: connected_components and quality_check need scipy, and without it those two tools fail at call time:

pip install 'netstead[mcp,graph]'

2. Test the server runs ¶

You don’t normally launch the server yourself — the MCP host does it. But --help confirms the entry point resolves and the SDK is importable:

netstead mcp serve --help

Expected:

Usage: netstead mcp serve [OPTIONS]

 Start the netstead MCP server on stdio (for Claude Desktop / Claude Code).
 ...
╭─ Options ─────────────────────────────────────────────────────────╮
│ --name          TEXT  MCP server display name. [default: netstead] │
│ --help  -h            Show this message and exit.                  │
╰───────────────────────────────────────────────────────────────────╯

3. Configure the MCP host ¶

Claude Desktop (macOS): edit ~/Library/Application Support/Claude/claude_desktop_config.json. On Linux it’s ~/.config/Claude/claude_desktop_config.json; on Windows, %APPDATA%\Claude\claude_desktop_config.json. Restart Claude Desktop after editing; the tools show up under a hammer-icon in the chat input:

{
  "mcpServers": {
    "netstead": {
      "command": "netstead",
      "args": ["mcp", "serve"]
    }
  }
}

Claude Code: register the server from the terminal — everything after -- is the command Claude Code launches:

claude mcp add netstead -- netstead mcp serve

--scope project writes it to a .mcp.json at the project root that teammates pick up on session start (the default scope is local to you); see claude mcp add --help. The equivalent hand-written .mcp.json is the same JSON as above. To use the version installed in a project venv, replace netstead with the absolute path to that venv’s netstead.

4. The tools shipped today ¶

The server exposes seven stateless tools. Every tool takes a source — any path or URL that Network.from_source accepts — and returns JSON; only scope_from_nodes takes anything more. Full input and output shapes are in the MCP tools reference.

Name	Summary	Inputs	Output
`describe_package`	Generic package overview: name, engine, table count, per-table rows + columns.	`source`	`{source, name, engine, table_count, tables: [{name, rows, columns}]}`
`validate_package`	Generic Frictionless validation (no GMNS spec). For GMNS use `netstead validate --json`.	`source`	`ValidationReport.to_dict()`
`list_tables`	Sorted table names, no row counts.	`source`	`["lane", "link", ...]`
`describe_network`	GMNS-aware overview: spec version, link + node counts, table names.	`source`	`{source, name, spec_version, engine, links, nodes, table_count, tables}`
`quality_check`	The GMNS data-quality rule pack. Needs `[graph]`.	`source`	`ValidationReport.to_dict()`
`connected_components`	Count + sizes of weakly-connected components. Needs `[graph]`.	`source`	`{source, component_count, sizes}`
`scope_from_nodes`	Node-seeded scope; returns the resulting node + link id sets.	`source`, `node_ids: [int]`, `path_between: bool = true`	`{source, seed_node_ids, path_between, result_node_count, result_link_count, node_ids, link_ids}`

5. Sample agent prompts ¶

Each of these exercises a different tool — paste them into a chat with the server configured to see the agent pick the right call:

“What’s in the GMNS network at packages/netstead/netstead/fixtures/leavenworth/csv?” — agent calls describe_network, returns spec version 0.97, 339 links, 121 nodes and the nine table names.
“Run the quality rules on that network and summarize the warnings by code.” — agent calls quality_check, groups the issues list by code, and reports the counts.
“Scope the network to the shortest paths between nodes 1, 25 and 50 and tell me how many links that is.” — agent calls scope_from_nodes with node_ids=[1, 25, 50] and path_between=true (the default). See the known issue on this tool in the MCP tools reference.

Common variations ¶

Default — stdio transport, system netstead

The simplest config: relies on netstead being on the MCP host’s PATH.

{
  "mcpServers": {
    "netstead": { "command": "netstead", "args": ["mcp", "serve"] }
  }
}

Rename the server in the host UI

--name becomes the label under the tool list in Claude.

"args": ["mcp", "serve", "--name", "gmns-leavenworth"]

Run inside a project venv

Use the absolute path to that venv’s netstead binary; avoids version skew with the system install.

{
  "mcpServers": {
    "netstead": {
      "command": "/path/to/.venv/bin/netstead",
      "args": ["mcp", "serve"]
    }
  }
}

Pin the server to a working directory

Adds cwd so all relative-path tool calls resolve from a known root.

{
  "mcpServers": {
    "netstead": {
      "command": "netstead",
      "args": ["mcp", "serve"],
      "cwd": "/abs/path/to/data"
    }
  }
}

Pass env vars (cloud creds)

Use env to inject credentials into the subprocess.

{
  "mcpServers": {
    "netstead": {
      "command": "netstead",
      "args": ["mcp", "serve"],
      "env": { "AWS_PROFILE": "ds-readonly" }
    }
  }
}

Pitfalls ¶

Stdio transport only today. The HTTP MCP transport is a follow-up — track the open issues for progress. For now, every agent that wants to call netstead needs to launch its own subprocess.
Tools are stateless. There’s no persistent edit_session tool yet — every call is a one-shot load + read. The agent can’t mutate a network and inspect intermediate state across calls. See the issue tracker for the design discussion.
JSON-only return values. Tool outputs are summaries (counts, names, id lists, reports), never table rows. For the data itself, the agent should call the CLI or the Python API through a shell tool.
Config file path is case-sensitive on macOS. Claude vs claude matters. If the server doesn’t show up after a restart, check ~/Library/Logs/Claude/mcp*.log.
